NT-2085L 2D Image Hands-Free Barcode Scanner Flatbed Desktop Bar code Reader
【Hands-free Operation Boosts Efficiency】
This innovatively designed desktop 2D barcode scanner features hands-free operation and can be securely placed on checkout counters, warehouse workbenches or office desks. With its ergonomic 15° tilt angle design, operators simply need to swipe product barcodes through the scanning zone without holding the device, improving work efficiency by over 30% compared to traditional handheld scanners. Particularly suitable for high-intensity repetitive scanning scenarios like retail checkout and inventory management, it effectively reduces operator fatigue and ensures lasting comfort.
【Smart Scanning with Effortless Operation】
Equipped with an extra-large scanning window (100mm×80mm) and wide-angle scanning engine, it easily captures barcodes of various sizes and angles. The advanced plug-and-play technology automatically recognizes the device as a keyboard input through standard USB 2.0 interface, requiring no driver installation or software configuration for true out-of-box readiness. Whether for temporary staff with limited technical knowledge or elderly users, everyone can start operating within 5 seconds, significantly reducing corporate training costs and time investment.
【Highly Customizable Functions】
Built-in powerful data formatting features allow users to easily configure:
Prefix/suffix addition (up to 16 characters)
Keyboard case conversion (auto/force uppercase/force lowercase)
Enter/line feed insertion
Data segmentation and truncation
These functions are particularly suitable for asset management, medical equipment tracking and warehouse management systems requiring strict data standards, ensuring collected data can be directly imported into various ERP/MES systems without secondary processing.
[Multilingual Support & Industry Adaptability】
Supporting over 20 international keyboard layouts (including QWERTY, AZERTY, QWERTZ) and Unicode special character input, it perfectly adapts to multinational enterprises' multilingual requirements. The scanner's intelligent sleep function (auto low-power mode after 30 seconds of inactivity) and anti-interference design enable stable operation in harsh environments from -10°C to 50°C. IP54 dustproof and waterproof rating ensures reliable long-term performance even in special venues like fresh supermarkets and outdoor warehouses, making it the ideal choice for enhancing modern business operation efficiency.
| Technical Specifications | |
|---|---|
| Resolution | 1280 × 800 |
| Light Source | 625nm Red LED |
| Angle | Horizontal 42° Vertical 31° |
| Supported Barcodes | |
| 1D Codes | UPC-A / UPC-E EAN13 / EAN8 / ISBN / ISSN Code128 / GS-128 Code39, Code93, Code32, Code11 Codabar, MSI, PLESSEY ITF25, STD25 Matrix25, IND25, HK25 Pharma Code Telepen Trioptic Code Brazilian Bank Code Postal Code GS1 Databar GS1 Composite Code |
| 2D Codes | QR Code / Micro QR Data Matrix PDF417 / Micro PDF417 Aztec Maxicode Hanxin |
| Performance | |
| Precision | 1D: 5mil Code 39 2D: 6.5mil QR Code |
| Contrast | 25% |
| Environmental | |
| Operating Temperature | -20°C ~ +50°C |
| Storage Temperature | -40°C ~ +70°C |
| Humidity | 5% ~ 95% (No Condensation) |
| Ambient Illumination | 0 ~ 100,000 LUX |
| Electrical | |
| Working Voltage | DC +5V ±5% |
| Start-up Current | 330mA |
| Stand-by Current | 190mA |
| Working Current | 240mA |
| Physical & Interface | |
| Interface | USB COM / Keyboard (RS232 Optional) |
| Size | 144 × 135 × 103 mm |
