N.B. Image may vary with product
Description
The PCIe x16 Intel E810 Dual-Port 100G network adapter two 100 Gigabit Ethernet ports, 100 Gigabit throughput performance, enhanced programmable packet processing pipeline, virtualization (enhanced SR-IOV support with up to 256 VFs and backward compatibility VF driver support), new features for the communications market (fine grained scheduler, transmit head support, adjustment of credits according to different headers, enhanced QoS, and enhanced burst control) and RDMA (iWARP and RoCEv2).It objective is to enable a scalable Ethernet controller suitable for enterprise, Cloud, and Communications Service Provider applications.
Intel E810 Dual-Port 100G NIC Specifications
| PCIe Compliance | PCI Express 4.0 specification (backward compatible with PCI Express 3.0) |
| Concurrency | 256 non-posted requests |
| Port Speeds Supported | 100/50/25/10/1 GbE |
| Throughput | 100Gb/s for TX & RX up to 80Mpps (TX), 90Mpps (RX) |
| Network Interfaces |
|
| Ethernet Port Configuration | Flexible via EPCT (Ethernet Port Configuration Tool) |
| Virtualization Features |
|
| Stateless Offloads | TCP/UDP segmentation offload, large segment offload, checksum offload |
| Time Sync | IEEE 1588 Precision Time Protocol |
| RDMA | Supports iWARP and RoCE v2 |
| DPDK | Enhanced DPDK for NFV acceleration and packet processing |
| Performance Features |
|
| Jumbo Frame | Up to 9728 bytes |
| Supported OS |
|
| Product Name | PCIe x16 Intel E810 Dual-Port 100G Network Card |
| Bus Type | PCIe Gen4.0 (16GT/s) x16 edge connector, Gen3 compatible |
| Controller | Intel E810-CAM2 |
| Ethernet Data Rate | 1/10/25/50/100 GbE |
| Network Connector Type | 2x QSFP28 |
| IEEE Standards |
|
| Protocol Support | 100GBASE-CR4/KR4, CAUI-4, 100GBASE-CR2/KR2, 100GAUI-2/4, 50GBASE-CR2/KR2/CR/KR, 50GAUI-1/-2, 25GBASE-CR/KR/CR1/KR1, 25G-AUI C2C/C2M, 10GBASE-KR, 10GSFI, 10G-SFP+ |
| Operating Temperature | 0°C to 105°C (32°F to 221°F) |
| Storage Temperature | -40°C to 115°C (-40°F to 239°F) |
| Bracket | Full-height installed, Low-profile included |
| Power Consumption | Max 15.67W |
| Dimensions | 167mm x 69mm |
| Virtualization Support | Next-gen VMDq, SR-IOV, VLAN, VxLAN, NVGRE, GENEVE |
| 1 x PCIe x16 Intel E810 Dual-Port 100G Ethernet Adapter |
| 1 x User&rsquos Manual |
| 1 x CD Driver |
| 1 x Low-profile Bracket |
| Accessories |
| Windows | Windows 11, Server 2016/2019/2022 |
| Linux | RHEL 9.1 / 8.7, SLES15 PS4, Ubuntu 22.04 / 20.04, Debian 11, FreeBSD 13 / 12.3 |
| Hardware | Available PCI Express x16 slot |
